Ridger HFI – 05

RIDGER HFI-05
Ridger HFI – 05
  • sed for making ridges for planting tobacco, potato and other vegetables. The ridger fully adjustable for giving different accurate row widths. To obtain the correct ridge profile and retain soil flow, the high grade mould boards are adjustable. The ridger can also be used for earthing up the crops sown in rows. The mouldbards of each ridger body are easily adjustable to give the exact ridge profile for maximum crop yield. The ridger bodies are staggered in formation to allow smooth soil flow with no blockages even when the machine is working at maximum depth. The frame and headstock are indentical to those used on the tiller so compatibility of parts or interchangeability of legs is easy and reduces cost.

    SPECIFICATION:



    Max. Row Spacing

    711 m (Decreasing in increments of 25 mm)

    Overall width

    1,778 mm

    Depth

    1,050 mm

    Clearance (under frame)    550 mm

    Weight                                                    145 kg.

    Tractor Compatibility       Above to 50 HP
