DISC PLOUGH HFI – 900
A heavy duty disc plough suitable for tractors from 50 to 150 horsepower capable of working of working in the most severe conditions.
TECHNICAL SPECIFICATION:
Number of Furrows | 2 | 3 4 | 5 | 6 |
Tractor Horsepower Suitability | 50-70 | 60-90 70-100 | 90-130 | 100-150 |
Furrow Width Adjustment |
| 8,9,10,11,12in |
| 8,9,10in |
by sliding disc hangers along frame
Disc Type/Size Plain inside or outside bevel or scalloped
26in
Maximum Working Depth mm (in) 305 (12)
Longitudinal Clearance mm (in) 725 (28.5)
Furrow Wheel mm (in) Adjustable vertically-laterally 510(20)
Disc Adjustment Vertical and lateral adjustment to suit conditions
Weight with 760mm (30in) discs kg 412 511 610 765 841 (lb) (908) (1126) (1345) (1687) (1854)
BENEFITS:
Extra weight can be fitted on the weight frame with tractor front weights to increase penetration in very hard conditions.
Box section frame (6in x 4in), A frame headstock and clevis lower link attachment points give strenght
© Copyrights 2006 Hanif Farm Ind.
and long life even with high horsepower tractors.
Disc angle adjustable vertically and laterally to assist penetration and quality of work.
Disc bearings are regreasable and sealed to prevent soil ingress.
The rear furrow wheel is adjustable vertically and laterally to exactly balance the side draft and ensure easy handling.
Scalloped discs are available to cope with large amounts of trash.
